Object-Oriented Design for Jigsaw Puzzle

1. Problem Statement

Design a simple, object‑oriented jigsaw puzzle system that models pieces and their edges, supports rotation, and assembles a complete image by matching complementary edges. Each piece has four edges (top, right, bottom, left); edges fit only with their complementary partner, and pieces may be rotated (90°, 180°, 270°).

Core goals:

• Represent pieces and edges with clear types (inner, outer, flat)
• Support rotation and orientation tracking
• Assemble by matching complementary edges until the puzzle is complete
• Favor clarity over full optimization; keep APIs clean and minimal

2. System Requirements

Functional Requirements:

• Model a puzzle piece with four edges and the ability to rotate (90°, 180°, 270°).
• Represent edge types and determine whether two edges fit (complementary shapes: inner/outer or flat for borders).
• Assemble pieces by matching complementary edges until the full solution is formed.

Non-Functional Requirements:

• Efficiency: ideally build adjacency in O(N) to O(N log N) where N is number of pieces (edge hashing / maps are recommended).
• Deterministic orientation: rotate pieces to a canonical orientation when connected.

Assumptions:

• Every edge fits with at most one complementary edge.
• Puzzle is rectangular and pieces have four sides.

3. Use Case Diagram

Actor: Solver (human or algorithm)

Use case summary: The Solver inspects pieces, rotates them, and places them by matching edges until the puzzle is complete.

graph TB
	subgraph "Jigsaw System"
		UC1["Inspect Pieces"]
		UC2["Rotate Piece"]
		UC3["Match Edge"]
		UC4["Place Piece"]
	end
	Solver([Solver])
	Solver --> UC1
	Solver --> UC2
	Solver --> UC3
	Solver --> UC4
	style Solver fill:#4CAF50,color:#fff

4. Class Diagram

Core classes and responsibilities (based on the provided pseudocode):

• Edge: models an edge with Type (inner, outer, flat), a parent piece reference, and a fitsWith method.
• Piece: holds four Edge objects (left, right, top, bottom) and supports rotation; tracks solvedOrientation.
• Puzzle / Solver: container for pieces, maintains lists of inner/outer/flat edges and exposed edges, and drives the solve() process.

classDiagram
	class Edge {
		+enum Type { inner, outer, flat }
		+Piece parent
		+Type type
		+boolean fitsWith(Edge)
	}

	class Piece {
		+Edge left
		+Edge right
		+Edge top
		+Edge bottom
		+Orientation solvedOrientation
		+void rotate(int degrees)
	}

	class Puzzle {
		+Piece[][] pieces
		+Piece[][] solution
		+List~Edge~ inners
		+List~Edge~ outers
		+List~Edge~ flats
		+List~Edge~ exposedEdges
		+void sort()
		+void solve()
	}

	Piece "1" -- "4" Edge : contains
	Puzzle "1" -- "*" Piece

5. Activity Diagrams

Activity: Build edge map and sort pieces

graph TD
	A[Iterate all pieces] --> B[For each edge classify as inner/outer/flat]
	B --> C[If complementary edge already in map -> link and rotate]
	C --> D[Else add edge to map]
	D --> E[Continue until all edges processed]

Activity: Place matching piece (solve step)

graph TD
	X[Take exposed edge] --> Y[Find matching complementary edge]
	Y --> Z{Found?}
	Z -- Yes --> P[Rotate matched piece to align]
	P --> Q[Place piece in solution and update exposed edges]
	Z -- No --> R[Mark edge unresolved]

6. Java Implementation

Skeletons adapted from the original pseudocode (structure and signatures only).

Java

class Edge {
		enum Type { INNER, OUTER, FLAT }
		Piece parent;
		Type type;

		public boolean fitsWith(Edge other) {
				// returns true if this edge complements `other`
				return false;
		}
}

class Piece {
		Edge left, right, top, bottom;
		int solvedOrientation; // 0, 90, 180, 270

		public void rotate(int degrees) {
				// rotate piece edges and update solvedOrientation
		}
}

class Puzzle {
		Piece[][] pieces; // pool of remaining pieces
		Piece[][] solution; // assembled board
		List<Edge> inners, outers, flats;
		List<Edge> exposedEdges;

		public void sort() {
				// classify edges and identify corners
		}

		public void solve() {
				// iterate exposedEdges and try to match and place pieces
		}
}

7. Python Implementation

from __future__ import annotations
from dataclasses import dataclass, field
from enum import Enum
from typing import List, Optional

class EdgeType(Enum):
		INNER = 1
		OUTER = 2
		FLAT = 3

@dataclass
class Edge:
		parent: "Piece"
		type: EdgeType

		def fits_with(self, other: "Edge") -> bool:
				return False

@dataclass
class Piece:
		left: Optional[Edge] = None
		right: Optional[Edge] = None
		top: Optional[Edge] = None
		bottom: Optional[Edge] = None
		solved_orientation: int = 0  # degrees

		def rotate(self, degrees: int) -> None:
				# rotate edges and update orientation
				raise NotImplementedError

class Puzzle:
		def __init__(self) -> None:
				self.pieces: List[List[Piece]] = []
				self.solution: List[List[Optional[Piece]]] = []
				self.inners: List[Edge] = []
				self.outers: List[Edge] = []
				self.flats: List[Edge] = []
				self.exposed_edges: List[Edge] = []

		def sort(self) -> None:
				# classify edges and find corners
				raise NotImplementedError

		def solve(self) -> None:
				# main solve loop: match edges, rotate pieces, place them
				raise NotImplementedError
